Reference: 400000006

Brand: DB TECHNOLOGIES

SNAP SLIDE FOR ES802 ES503 COUPLE A + B

Review(s): 0
Top Look repair Kit the Kit is composed of 2 pieces (A + B as in the photo.) FOR THIS ITEM THE MAXIMUM THAT CAN BE ORDERED IS 2 KITS. !! ORDERS PLACED WITH QUANTITIES OVER 2 KITS WILL NOT BE PROCESSED !! SPARE FOR MODEL ES802 ES503
€22.00
More
IN STOCK

Reference: 33935

Brand: FBT

UcD180LPV8 Amplifire Module Hypex 180W FBT

Review(s): 0
UcD180LPV8  Amplifire Module  Hypex 180W FBT the straightener is sold new and tested before being packaged and shipped. !! ATTENTION!! replacing this component requires technical intervention which must be carried out by competent personnel. AUDIOLIVE is not responsible in any way for any damage caused to things or people, by the incorrect assembly of...
€43.90
More
Out-of-Stock
All best sellers
  • Out-of-Stock
REGENERATED WOOFER 4 OHM FOR  DVA S30/ S2585N/ S1518N/ S1518N/ S10
  • REGENERATED WOOFER 4 OHM FOR  DVA S30/ S2585N/ S1518N/ S1518N/ S10
  • REGENERATED WOOFER 4 OHM FOR  DVA S30/ S2585N/ S1518N/ S1518N/ S10

REGENERATED WOOFER 4 OHM FOR DVA S30/ S2585N/ S1518N/ S1518N/ S10

401020078RR
Rating

WOOFER NEODIMIO SPARE PARTS FOR DVA SUB SERIES

DVA S10
DVA S1518N
DVA S20
DVA S2585N
DVA S30N
€268.00
VAT included
Quantity
Out-of-Stock

  Sostituzione Accettata

nel caso ci siano problemi durante il trasporto o eventuale merce inviata guasta.

Description
  • • Nominal Diameter: 460 / 18 mm/inch;
  • • Rated Impedance: 4 Ω;
  • • Program Power: 3000 W AES;
  • • Power handling capacity: 1500 W AES;
  • • Sensitivity: 97.5 dB;
  • • Frequency Range: 25 Hz ÷ 1000 Hz;
  • • Effective Piston Diameter: 395 / 15.6 mm/inch;
  • • Max Excursion Before Damage (peak to peak): 50 / 1.97 mm/inch;
  • • Minimum Impedance: 2.5 Ω;
  • • Voice Coil Diameter: 100 / 4 mm/inch;
  • • Voice Coil Material: Copper;
  • • Voice Coil Winding Depth: 30 / 1.18 mm/inch;
  • • Number of layers: 2;
  • • Kind of layer: inside / outside;
  • • Top Plate Thickness: 15 / 0.6 mm/inch;
  • • Cone Material: No pressed pulp;
  • • Cone Design: Straight;
  • • Surround Material: Polycotton;
  • • Surround Design: Triple roll;

Product Details
401020078RR
401020078RR
New

Data sheet

SPEAKER TYPE
WOOFER
DIMENSIONS
COIL IMPEDANCE
4 OHM
SPEAKER POWER
SPARE PARTS FOR

If you are a technical assistance center or a reseller and have an European intra-community VAT number, you can purchase and receive an invoice without the tax.
